WasteAway 270l-750
WasteAway 270l-750
All systems are New Zealand made and assembled
Plus Freight
The WasteAway 270l Septic Pumping Station is designed for in-ground installation and comes with a hard wearing 750w stainless steel pump. New Zealand made and built to last.
We can also build the tanks with different pump options to suit your needs.
Please contact us for freight price.
Warranty:
Tank- 20 year Warranty Limited
Pump- 2 Year Limited
Get in touch with us today to discuss your options
Specifications
| Tank capacity | 270 litre |
| Tank dimensions | h790mm x d710mm |
| Pump | 750w |
| Flow Rate | 15,000 Litres/Hour |
| Pumps | 80m horizontally or 6m vertically |
| Pump voltage | 240v |
| Inlet (to the tank) | 100mm |
| Inspection hatch | 450mm |
| Tank outlet (from the pump) | 40mm |
| Lead Length | 10m |
WARNING
You must not flush excess grease and fat or sanitary products like baby wipes or tampons down the drain as it will block and potentially damage the pump voiding the warranty.
270l WasteAway System Installation
How to bury the tank
Our 270l tanks can be either partially or completely buried below ground. Your 270l WasteAway wastewater tank is manufactured to specifications that allow it to be completely buried with up to 150mm of material above the manhole cover. Please read the following instructions before installation.
-
It is recommended that the septic tank be kept upright during transportation, to stop any of the pipework from moving.
-
Dig a hole for the wastewater tank, large enough for the tank to be placed in the hole with room for access to the inlet/outlet pipe connections and a minimum of 150mm around the diameter of the tank for clean backfill material.
-
Ensure that the base of the hole is level. Lay quarry dust or sand in the base of the hole 50-100mm thick.
-
Attach the inlet and outlet piping to the tank pipe fitting and glue them into place.
-
Backfill/bury tank with sand. Do not use rocks, stony material or heavy clay.
If the tank is to be buried more than 150mm, it is recommended to lay 50mm thick ground retention treated timbers over the tank supported by the ground each side of the tank before filling. This will ensure the tank dome is protected from excessive weight. Back fill with clean light material.
If in doubt please don't hesitate to contact Ross on 0277742435.
- Brass Swing Check Valve
- Quick release union
- Tough UV-resistant tanks
- Gas-tight inspection hatch for cleaning and servicing
- 10m lead with 3-pin plug
- 20 year back-to-base warranty
